Sliding Window
Features
Frame Widths
Sliding Windows are available in 48,65,75 & 100mm frame widths; in finned, finless and face fix configurations. These systems can also be double glazed (18mm pocket ) with adapters. Interchangeable sashes fit all 3 frame widths.
Structural
Hollow sections give added strength and security. Heavy duty double rollers are standard on all Sliding Windows, which last longer and operate smoother than conventional types. Rounded hollow stiles add to the strength & will not catch on window coverings. The sash sits completely inside the frame which resists rolling of the top and bottom sash rail under high wind loads, with increased daylight opening
Weather
All Sliding Windows achieve a minimum water penetration resistance pressure of 250Pa. Varying the sill type will achieve rating up to 600Pa. All wind load categories are catered for Australia wide. Our hollow sill design helps achieve maximum weatherability.
Aesthetics
No unfinished or exposed edges. No internal projection of transom and sash sections. Sash rail top & bottom are concealed within the sill and frame. Genuine handles are ergonomically designed for ease of use for the elderly and disabled. The handles operate in the direction of the sash movement and are available in 4 colours.
Maintenance
With an easy clean sill design, window cleaning is safer with rounded edges.
Options
Multi-position vent locking available. Standard or barrel key locking available, Inscet / Security screens.
Glazing thickness to 6.38mm as standard. Thicker glass and double glazing available.
The flush rails to sill design gives increased strength and clear sight lines
Non corrosive double wheel rollers
Flat sill for ease of cleaning
